High Power Ultrasonic Assembly For 15kHz Sealing N95 Mask

High Power Ultrasonic Assembly For 15kHz Sealing N95 Mask

Description:

Ultrasonic welding is the clean, fast and reliable method of joining non-woven, It is the use of ultrasonic frequency mechanical vibration energy in the work-piece surface to produce the plastic deformation and failure under the pressure surface, realize the welding method. The non-woven fabric layer of the medical mask is mainly made of polypropylene fiber material with high solubility, which belongs to the fiber material with high solubility of polypropylene products. Ultrasonic welding system can weld non-woven fabrics well, environmentally friendly, sterile, efficient and strong.

Specification:

Frequency: 15kHz

Max Power: 2600Watt

Voltage: 110V / 220V, 50-60Hz

Working Temperature：5°C - 50°C

Generator：Analog

Steel horn: 200*25mm

Advantage:

1. Ultrasonic is the fastest, most repeatable and economical assembly method available to the industry today.

2. With ultrasonic, most thermoplastics can be assembled without heat, mechanical fasteners, or hazardous consumables such as adhesives or solvents.

3. Ultrasonic can join parts - small or large, simple or complex - with lower reject rates than any other method.

4. Using ultrasonic, labor - both as a skill factor and as a time factor - is significantly reduced. And since the equipment can readily be automated, any non-technical operator can be trained in minutes to produce high volume, high integrity assemblies.

Structure:

Ultrasonic Generator: 1pc

Ultrasonic Transducer: 1pc

Ultrasonic Booster: 1pc

Ultrasonic Horn: 1pc
