The 2000 Watt 20 kHz Ultrasonic Converter Direct replacement for the Dukane 41C30 that delivers lower cost, rugged quality and superior value.
Item No.:
HS-D41C30Payment:
T/T, Paypal, Western UnionProduct origin:
ChinaColor:
Sliver and YellowShipping port:
Hangzhou or ShanghaiLead Time:
7
Description:
The 2000 Watt 20 KHz Ultrasonic TRANSDUCER Direct replacement for the Dukane 41C30 that delivers lower cost, rugged quality and superior value. Ultrasonic transducer is a device that converts electrical energy into mechanical energy. Ultrasonic transducers convert AC into ultrasound, as well as the reverse. Ultrasonics, typically refers to piezoelectric transducers or capacitive transducers. Piezoelectric crystals change the size and shape when a voltage is applied; AC voltage makes them oscillate at the same frequency and produce ultrasonic sound.
Specification:
Item No
HS-D41C30
Frequency
20 kHz
Power
2000 watt
Connect screw
1/2-20 UNF
Diameter of ceramic
50 mm
Quantity of ceramic
4 pcs
Capacitance
11-17 nF
Advantages:
1. Titanium, aluminum, steel materials of horn optional.
2. Once assembled, the transducers are aged before testing and final assembly. The properties of piezoelectric materials can change with time and pressure, so a bit of time on the shelf prior to testing will identify nonconforming material.
3. One by one testing to ensure that each transducer performance are excellent.
4. In good heat resistance, can be used in a wide range of temperature with long life and high reliability.
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
