Home Ultrasonic Welder Repair Branson

Branson Type Converter

Replcement Converter For Branson 922JA 2000 Watt 900 Series Branson Actuator And IW Systems

Replcement Converter For Branson 922JA 2000 Watt 900 Series Branson Actuator And IW Systems

Replcement Converter For Branson 922JA 2000 Watt 900 Series Branson Actuator And IW Systems

  • Item No.:

    HS-B922JA
  • Payment:

    T/T, Paypal, Western Union
  • Price:

    $699/PC
  • Product origin:

    China
  • Color:

    Silver
  • Product weight:

    5Kg
  • Shipping port:

    Shanghai or Ningbo
  • Lead Time:

    5
  • Product Details



Replcement Converter For Branson 922JA 2000 Watt 900 Series Branson Actuator And IW Systems





Specification:


 Item No.:  HS-B922JA
 Frequency:  20kHz
 Power:  2000Watt
 Connect Screw:  1/2-20UNF
 Ceramic Diameter:  50mm
 Qty of Ceramic:  6PCS
 Amplitude:  20um
 Color of Ceramic:  Yellow


Advantage:

1.High Efficiency of high mechanical factor. High transfer efficiency is obtained when working in resonance frequency.

2.Big amplitude designed and chosen by computer, high oscillation speed and big amplitude in front operculum.

3.Big Power under the function of the prestressed force screw rod, the piezoelectricity ceramics can work freely in the highest level of power.

4.In good heat resistance of small resonance impedance, less heat produced, can be used in a wide range of temperature with long life and high reliability.



Description:

Replacement Branson 922JA ultrasonic transducers are made of Imported ceramic discs and surperior aluminum raw materials. We can replace the front and back cover of the transducer as per to the need. This transducer is uesd for ultrasonic welding machine, ultrasonic sonochemistry, ultrasonic atomization ultrasonic cutting machine, etc.



Leave A Message

If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
