The Ultrasonic Converter replacement for Branson Plastic Welding Machine Direct replacement for the Branson machine that delivers lower cost, rugged quality and superior value.
Item No.:
HS-B803Payment:
T/T, Paypal, Western UnionPrice:
$699/PCProduct origin:
ChinaColor:
GoldShipping port:
Hangzhou or Shanghai
1500w Replacement Branson 803 Ultrasonic Welding Transducer Connect Screw 1/2-20UNF
Description:
The Ultrasonic Converter replacement for Branson Plastic Welding Machine Direct replacement for the Branson machine that delivers lower cost, rugged quality and superior value.
First, all of the parts are all new.
The parts are made from certified materials in tightly controlled manufacturing processes, assembled andtested in a climate-controlled environment using carefully calibrated equipment, then properly aged and re-tested to ensure performance that duplicates the OEM part.
Specification:
Item No.: HS-B803
Frequency: 20kHz
Power: 1500Watt
Screw: 1/2-20unf
Ceramic disc Diameter: 50mm
Quantity of Ceramic discs: 4 or 6 pcs
Capacitance: 11.5-12.5nf
Amplitude: 20um
Competitive Advantage:
1. Titanium materials and Aluminum materials optional.
2. Once assembled, the transducers are aged before testing and final assembly. The properties of piezoelectric materials can change with time and pressure, so a bit of time on the shelf prior to testing will identify nonconforming material.
3. One by one testing to ensure that each transducer performance are excellent.
4. In good heat resistance, can be used in a wide range of temperature with long life and high reliability.
What we can do for you,
1. OEM - special custom-made the ultrasonic transducers or parts for you, and save cost for you.
2. Supply Replacement converter - Including NTK, Branson CJ20, CR20, 922JA..., Dukane 110-3122, Rinco brand and so on.
3. For some special items, you can provide us with samples, then we can give you a competitive price and custom-made it for you.
Previous :
Replacement Ultrasonic Converter Branson902Next :
1100W Yellow Ceramic Ultrasonic Welding Transducer for Replacement Branson 902If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
