The booster is used to connect the transducer and the horn, and the amplitude can be adjusted to ensure maximum power output.
Item No.:
HS-5020-4ZMin order:
10Product weight:
3kgHigh Quality Portable Handle Ultrasonic Armature Welding Boosters
Quick Detail:
15Khz Ultrasonic Transducer With Booster
Higher quality of electronic component
Imported ceramic chip
Description:
Ultrasonic Oscillator is the main part of high-power ultrasonic system, include booster and Transducer (converter). Ultrasonic booster can change the amplitude of transducer. Booster is a passive device and cannot produce vibration itself. It is only to output after the input vibration is changed into amplitude, and finishing the impedance conversion at the same time. Under the stimulus of electric field, ultrasonic transducer can produce regular vibration and the amplitude is about 10μmm commonly. That is not enough to finish the welding and processing step directly. Through with the suitable booster, the amplitude of ultrasonic can be changed in a large range.
Applications:
Ultrasonic Oscillator is used for ultrasonic cutting machine. It’s the core of ultrasonic cutting equipment.
Specifications:
|
Model |
VA-3828-2Z |
| Package Type |
Through Hole |
| Frequency |
28 KHz |
| Capacitance |
7500-12500 pF |
| Dimension |
30mm |
| Booster |
1 |
| Material |
Stainless Steel |
| Color |
Black |
| Piezoelectric Chip |
2 |
Competitive Advantage:
★ High mechanical quality and excellent electro-acoustic conversion efficiency, providing a high output amplitude.
★ Piezoelectric element offer a high speed of vibration. Through bolt-on mounting, mechanical intensity and amplitude have been improved.
★ Having steady output amplitude even the load markedly changed.
★ Extended using temperature, ensuring good amplitude linearity. Lower resonant impedance, ensuring high conversion efficiency.
★ Bolt-on mounting gives the fast, easy installation and high reliability.
Workshop:
CE:
Packing&Shipping:
Shipping Port:Shanghai
Shipping Term:By express,by air,by ocean and so on.
Leading Time:Quick production leading time and fast delivery.Usually 1-3days if we have in stock.
Payment:
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
