Altrasonic 20KHZ 2000Watt Ultrasonic Aluminum-plastic Pipe Welding Machine Welding Equipment for Cooper Heating Tube Welding

Altrasonic 20KHZ 2000Watt Ultrasonic Aluminum-plastic Pipe Welding Machine Welding Equipment for Cooper Heating Tube Welding

By using the principle of ultrasonic high-frequency

vibration, the ultrasonic metal welding machine converts

ultrasonic vibration energy into friction energy, thereby

transferring the metal surface. Under conditions where

heat is generated by friction and pressure is applied to the

metal, the metal sheet will melt.


  • Payment:

    T/T, PayPal, Western Union
  • Product origin:

    China
  • Color:

    Silver
  • Shipping port:

    Shanghai or Ningbo
  • Lead Time:

    40
  • Product Details


Ultrasonic Aluminum-plastic Pipe Welding Machine 20khz Solar Collector Plate Welding Equipment Copper Tube and Aluminum Foil Welding


Specification:



1. Frequency: 20±1kHz

2. Maximum output power: 2000Watt

3. Welding speed: 4-10m/min (according to the thickness of the material)

4. Aluminum welding thickness: 0.2-0.5mm (according to the material)

5. Welding tool head diameter: 51mm in diameter

6. Operation mode: automatic, manual test

7. Working pressure: 0.2-0.6Mpa

8. Power supply: AC220V±5%, 50Hz±1%

9. Dimensions: Generator: 450×600×160mm3 Support: 400×330×220 mm3

10. Working environment temperature: 0-50℃ 11. Motor: three-phase AC 220V conversion motor (51KGV20)


Advantages:



1. Simple structure and easy installation;

2. Flexible, can be used alone or in other systems;

3. Reliable system to ensure production yield;

4. Unique rotating structure design, no need to replace spare parts, saving cost;

5. The welding tip is made of special steel, which can withstand abrasion through strict production process.



Ultrasonic machining effect:



1(1)2(1)3(1)
