Home Ultrasonic Sewing Machine

35kHz Sewing Machine

35khz 800w Ultrasonic Heat Sealing Machine for Non-woven Fabric

35khz 800w Ultrasonic Heat Sealing Machine for Non-woven Fabric

35khz 800w Ultrasonic Sealing Machine for Non-woven Fabric, TPU, PP, PVC materials.

  • Item No.:

    HS-WS35-S
  • Payment:

    T/T, Paypal, Western Union
  • Product origin:

    China
  • Product Details


35khz 800w Ultrasonic Heat Sealing Machine for Non-woven Fabric



Description:



The work method of Seamless sewing part is completely imitating traditional sewing machine. The biggest characteristic is the ultrasonic transmit horn work direction is same with the sewed cloth. Which will make the sewed point of the cloth are even, flat and fastness. Through suitable design, it can reach perfect sewing effectiveness.



Specifications:


Model

HS-WS35-S

Frequency

35 KHz

Power

800 W

Rotary Welding Horns Width

12 mm

Power Adjust Method

File or Continuous

The Horns Surface Hardness

More than HRC56

Real-time Display

Working Frequency and Working Current

Allowable Rotation Speed

50 r/min.


Principle:


With ultrasonic sealing, the heat required for melting is only generated inside the thermoplastic sealing layer. For localized conversion of vibrations to friction heat, the anvil or sonotrode profiles are mostly linear. These profiles ensure focusing of the energy input and therefore short sealing times between 100 and 200 milliseconds. With ultrasonic sealing heat is generated at the inside of the film, not by heat input from the outside as is the case with heat sealing, for example. The tools (sonotrode and anvil) that come into direct contact with the packaging material, remain cold during the entire weld process. The support layer remains almost cold and upon termination of energy input, the heat dissipates faster to the outside due to the temperature difference between the support layer and the sealing layer so that the hot-tack resistance is significantly higher.


Function:



Raw material - Bag mouth fold - thermal bonding - side fold - bottom sealing - loop handle fix - thermal bonding - edge cut - bag cut - collection


Applications:


Usually used in clothing industry is the ultrasonic lace machine, which is mainly used in cutting and welding cloth. Owing to its transmit horn is a plane, so it only can turn its own geometric center and cant turn the same direction with the cloth. Which make the sewed point of the cloth is unevenness. The transmit horn of Seamless sewing part is a circumference horn, and can turn around . For the cloth, it is jointing with the cloth and working at the same time. The ultrasonic seamless sewing part advance ultrasonic lace machine and its market prospects are very bright.



Workshop:



CE:



Packing&Shipping:


Shipping Port:Shanghai

Shipping Term:By express,by air,by ocean and so on.

Leading Time:Quick production leading time and fast delivery.Usually 1-3days if we have in stock.




Payment:
