Ultrasonic terminal welding machine can weld wires, cables, copper stranded wires, copper braided wires (copper braids) and terminals together.
Item No.:
HS-2020-DPayment:
T/T, Paypal, Western UnionProduct origin:
ChinaColor:
SilverShipping port:
Shanghai or Ningbo20kHz Ultrasonic Terminal Metal Welding Machine for Copper Aluminum
Specifications:
Frequency
20 kHz
Power
2000 watt
Working air pressure
0.2~0.8Mpa
Capacity
35 mm²
Generator
Digital
Net weight
55 KG
Machine size
350*200*300mm
Generator size
450*200*200mm
Principle:
The welding principle of the ultrasonic terminal metal welding machine is to convert high-frequency electric energy into mechanical vibration energy through a transducer to act on the workpiece, and generate high-frequency friction between the surfaces of the two workpieces, until the surfaces of the two workpieces are heated and welded together. High-tech equipment. Parallel welding can be performed on bare copper wires. The ultrasonic welding process is a mechanical process. No current flows through the workpiece and no melting occurs. Its electrical and thermal properties are beyond the reach of other processes. Compared with fusion welding, ultrasonic welding has low consumption, long life and low labor intensity.
Application：
Ultrasonic terminal welding machine can weld wires, cables, copper stranded wires, copper braided wires (copper braids) and terminals together. This process is suitable for the automotive industry and the electronics industry. It can weld wires of different sizes to the terminals to achieve the best results in the welding of automotive wires and wires in the electronics industry.
Workshop:
CE:
Packing&Shipping:
Shipping Port:Shanghai
Shipping Term:By express,by air,by ocean and so on.
Leading Time:Quick production leading time and fast delivery.Usually 1-3days if we have in stock.
Payment:
