Ultrasonic Processing of Particles: Mixing

Ultrasonic Processing of Particles: Mixing

Ultrasonic Processing of Particles: Mixing

  • Payment:

    100% TT IN ADVANCE
  • Product origin:

    CHINA
  • Product weight:

    17Kg
  • Shipping port:

    Shanghai/Ningbo
  • Product Details

Ultrasonic Processing of Particles: Mixing, Emulsifying, Dispersing, Milling



Minimum Order Quantity:

1 Set

Price:

Ask for quote

Packaging Details:

Foam case

Delivery Time:

In 7 Working Days

Payment Terms:

T/T, WESTERN UNION

Supply Ability:

100 Sets/Month

Ultrasonic is an innovative technology that is used successfully for sonochemistry synthesis, deagglomeration, dispersion, emulsifying, functionalization and activation of particles. Particularly in nanotechnology, the ultrasonication is an essential technique for the sysnthesis and processing purposes of nano-size materials. Since nanotechnology has gained this outstanding scientific interest, nano-sized particles are utilized in extraordinarily many scientific and industrial fields. Also the pharma branch has discovered the high potential of this flexible and variable material. Consequently, nanoparticles are involved into various functional applications in the pharmaceutical industry, these include:

  • drug delivery
  • diagnostic products
  • product packaging
  • biomarker discovery

As nanomaterials are defined as particles with a dimension less than 100nm this means that the production and processing of these substances require higher efforts.

 Method  Particle size The number of particles  Effect
 Grinding > 10μm 1010  nonuniform
 Comminution by Gas Stream > 10μm 1010  nonuniform
 Emitting Smoke Bomb > 6μm 1011  nonuniform
 Ultrasonic Dispersion < 4μm 1013 uniform



Specifications:

Model

S-P20-1000

S-P20-1500

S-P20-2000

S-P20-3000

Frequency

20±1 KHz

20±1 KHz

20±1 KHz

20±1 KHz

Power

1000 W

1500 W

2000 W

3000 W

Voltage

220±10% V

220±10% V

220±10% V

220±10% V

Temperature

300

300

300

300

Pressure

35 MPa

35 MPa

35 MPa

35 MPa

Intensity of sound

20 W/cm²

30 W/cm²

40 W/cm²

60 W/cm²

Max Capacity

> 10 L/Min

> 15 L/Min

> 20 L/Min

> 30 L/Min

Material Of Tip Head

Titanium Alloy

Titanium Alloy

Titanium Alloy

Titanium Alloy
