Noiseless Ultrasonic Sealing Equipment For PU Fabrics Ultrasonic Roller Welding Machine

  • China
  • Altrasonic
  • HS-SW-35
  • Silver
  • 1
  • 20
  • TT, West union, Paypal

  • Contact Now
Product Details



Noiseless Ultrasonic Sealing Equipment For PU Fabrics Ultrasonic Roller Welding Machine




Description :


The ultrasonic seamless sewing machine technology skillfully uses the principle of ultrasonic bending vibration to convert the length of the high-frequency ultrasonic longitudinal vibrator into the diameter of the bending vibrator. Moreover, the direction of vibration is also rotated by 90 degrees, which converts the longitudinal vibration into the radial vibration of the disc horn, and the installation method is also changed from vertical cloth installation to parallel cloth installation. This greatly reduces the volume of the vibration system itself, and the installation size is greatly reduced, the whole machine is beautiful, the volume is reduced, and the weight is greatly reduced.



Specification:


Item No.: HS-S35

Frequency : 35kHz

Power : 800watt

Rotary welding horn width : 12mm

Power adjust method : File or continuous

The horn surface hardness : More than HRC56

Rate electricity : 6A

Jointing width : 1-5mm

Jointing speed : 1-10m/min

Working air pressure : 3-4kg/cm²

Exterior dimension (mm) : 1300(L)*600(W)*1100(H)

Net weight : 99KG



Advantage:


1. Cleanly cut and seal edges of synthetics and nonwovens

2. Eliminate fraying, unraveling, and material build-up

3. Need no needles, threads, adhesives, or other consumables

4. Four times faster than sewing machines

5. Ten times faster than adhesive machines

6. Minimal operator training required



Application:


It is mainly used for sewing seam, sewing, cutting and embossing of synthetic fiber cloth. It has good watertightness, high production efficiency, no needle and thread accessories, smooth and no burr in melting surface, and good hand feel. Ultrasonic lace sewing machine is widely used in clothing, toys, food, environmental non-woven bags, masks (cup masks, plane masks, three-dimensional masks, etc.) and other industries.


Workshop :

CE :



Shipment :



Payment :
