High-Intensity Ultrasound Equipment For Crude Oil Desulfurization
High-Intensity Ultrasound Equipment For Crude Oil Desulfurization
Minimum Order Quantity: |
1 Set |
Price: |
|
Packaging Details: |
Foam case |
Delivery Time: |
In 7 Working Days |
Payment Terms: |
T/T, WESTERN UNION |
Supply Ability: |
100 Sets/Month |
Description:
Ultrasound Equipment For Crude Oil Desulfurization
Ultrasound oxidative desulfurization technology is a new desulfurization technology. The chemistry of this technology with the ASR-2 technology is basically the same, except that SulphCo technology uses ultrasonic reactor, enhanced reaction process, desulfurization effect is more ideal. The process is described as: raw materials and water containing an oxidizing agent and catalyst is mixed in the reactor, in the role of ultrasound, small bubbles burst quickly produce and so vigorous mixing oil and water phases in a short time ultrasound also It enables local temperature and pressure of the mixed materials within the rapidly increased, and the material produced in the mixing hydrogen peroxide reacted sulfide; removal by solvent extraction sulfones and sulfates, recycled regenerated solvent, a sulfone, and sulfates We can produce other chemical products.
Specifications:
Model |
S-P20-1000 |
S-P20-1500 |
S-P20-2000 |
S-P20-3000 |
Frequency |
20±1 KHz |
20±1 KHz |
20±1 KHz |
20±1 KHz |
Power |
1000 W |
1500 W |
2000 W |
3000 W |
Voltage |
220±10% V |
220±10% V |
220±10% V |
220±10% V |
Temperature |
300 ℃ |
300 ℃ |
300 ℃ |
300 ℃ |
Pressure |
35 MPa |
35 MPa |
35 MPa |
35 MPa |
Intensity of sound |
>20 W/cm² |
>30 W/cm² |
>40 W/cm² |
>60 W/cm² |
Max Capacity |
> 10 L/Min |
> 15 L/Min |
> 20 L/Min |
> 30 L/Min |
Material Of Tip Head |
Titanium Alloy |
Titanium Alloy |
Titanium Alloy |
Titanium Alloy |
PS:If you need more power, we can install two or more device.
Competitive Advantage:
★ Without changing the customer production equipment and the existing process
★ Simple installation, the standard flange butt joint installation
★ Micro molecular interaction, direct, obvious effect
★ High power, high yield
★ Reduce cost, energy consumption
