Ultrasonic machining (UM or USM) is a non-thermal, non-chemical and non-electrical process that keeps the chemical composition, material microstructure and physical properties of the workpiece constant. Sometimes referred to as ultrasonic impact grinding (UIG) or vibratory cutting, this process can be used to create a variety of complex features in advanced materials.
Item No.:
HS-M20Payment:
T/T, Paypal, Western UnionProduct origin:
ChinaColor:
Green SilverShipping port:
Shanghai or Ningbo
BT30 BT40 Ultrasonic Machining Center Milling Cobalt Dioxide
Description:
Ultrasonic machining (UM or USM) is a non-thermal, non-chemical and non-electrical process that keeps the chemical composition, material microstructure and physical properties of the workpiece constant. Sometimes referred to as ultrasonic impact grinding (UIG) or vibratory cutting, this process can be used to create a variety of complex features in advanced materials.
Specification:
| Frequency | 20kHz |
| Output Power | 500W |
| Voltage | 220 V / 110V |
| Switch | Handle or foot switch |
| Power Adjusting | Step or continuous |
| Working Time Control | 24 Hours |
| Weight | 30 KG |
| Application | Ultrasonic Milling |
| Generator | Digital Generator |
| Length of cable | 5M |
Our product advantages:
• Modular integrated circuit for easy fixing and repair.
• Ultrasonic frequencies are automatic tracking and automatic scanning.
• Output power is greater than other brands.
• Ergonomically designed for ease of use and operation.
• Built-in fully automatic protection circuit.
• Safe application, stable and reliable operation.
• Fuse to protect the machine; cooling device for protecting the ceramic transducer.
• Use imported electronic parts and special rugged and durable parts.
• Each machine will perform a professional QC inspection before shipment
• After sales service is available.
• Using advanced digital integrated circuits, GW is lightweight, saving both shipping costs and portability.
• Power and amplitude can be adjusted between 50% and 100%.
• Use special plugs and sockets for the best connection and avoid poor machine connections.
Application:
1. Function: cutting, drilling, milling, etc.
2. Mass production of high-speed machining of various small parts and complex parts, diversified processing;
3. The complicated process can be completed in one time
4. Provide a full range of accessories
5. High precision
6. Easy to operate and easy to maintain
Previous :
HSK63A HSK63F Ultrasonic Hard Material Machining Composite MaterialNext :
Without Wires Ultrasonic Grinding Machine HSK63F Titanium AlloyIf you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
Categories
New Products
High Efficiency 28khz Ultrasonic Sealing and Cutting Machine for Plastic Film Packing Bag Read More
Ultrasonic Welding Generator for N95 Mask Making Analog 15k Generator Read More
40kHz 800Watt Ultrasonic Converter BNC Connect Replace Branson 4TH Read More
Processing Special Surface of Mould Amplitude Stability Ultrasonic Milling Equipment Read More
New Product Clothing Manufacturing Rotary Sealing Machine Ultrasonic Sewing Machine Read More
During ultrasonic drilling, the material is removed by micro-grinding or abrasive particle erosion. The tool oscillates at a frequency of approximately 20 kHz by a piezoelectric sensor and an electric oscillator. The tool forces the abrasive grit to normally impact the work surface in the gap between the tool and the workpiece to machine the work surface.
During ultrasonic drilling, the material is removed by micro-grinding or abrasive particle erosion. The tool oscillates at a frequency of approximately 20 kHz by a piezoelectric sensor and an electric oscillator. The tool forces the abrasive grit to normally impact the work surface in the gap between the tool and the workpiece to machine the work surface.
During ultrasonic drilling, the material is removed by micro-grinding or abrasive particle erosion. The tool oscillates at a frequency of approximately 20 kHz by a piezoelectric sensor and an electric oscillator. The tool forces the abrasive grit to normally impact the work surface in the gap between the tool and the workpiece to machine the work surface.
Customized Knife Handle Ultrasonic Vibration Spindle With Power Control
Ultrasonic machining (UM or USM) is a non-thermal, non-chemical and non-electrical process that keeps the chemical composition, material microstructure and physical properties of the workpiece constant. Sometimes referred to as ultrasonic impact grinding (UIG) or vibratory cutting, this process can be used to create a variety of complex features in advanced materials.
Customized Knife Handle Ultrasonic Vibration Spindle With Power Control
During ultrasonic drilling, the material is removed by micro-grinding or abrasive particle erosion. The tool oscillates at a frequency of approximately 20 kHz by a piezoelectric sensor and an electric oscillator. The tool forces the abrasive grit to normally impact the work surface in the gap between the tool and the workpiece to machine the work surface.
Ultrasonic milling has proven to be an effective technique for improving titanium, aluminum and stainless steel workability. Under the action of ultrasonic milling, it has more advantage than the traditional milling. In contrast to the effect of ultrasonic machining aluminum, steel, stainless steel, titanium four metallic materials.Improved surface quality of the most prominent is the titanium and aluminum, can improve the cutting ability of the most prominent is the stainless steel, the quality of the workpiece side is the most significant improvement in steel.
