High Speed 70khz Ultrasonic Wire Coil Embedding for Smart Card


The existing ultrasonic embedding wire embossing machine basically adopts a professional motion controller with a high-speed CPU to ensure the high-speed response of complicated mechanical actions and complete complex multi-axis motion control so as to realize the precision embedding of complex products. The vacuum suction plate Absorbing material embedding, effectively ensure the accuracy of the antenna embedding a smooth; embedding thread buried by ultrasonic technology, the entire process of program control fully automatic operation, easy operation, stable and reliable operation; using two automatic cycle switching workbench Plate, refueling without downtime, high production efficiency; each group of buried wire antenna group are independent units, both at the same time, you can also choose one of the groups at the same time work, high flexibility. Winding process than the traditional winding machine to be fast, save manpower, and more stable performance.






Power Adjusting

Step or continuous


Handle , foot switch,or linked outside

Working Time control



Digital generator


2M,  national standard

The threading hole

Ø0.5m or design according to customers' need

Cooling down method

Compressed air

Outer housing

aluminium or nylon


The Advantage of Smart card antenna welding machine, smart card spot welding machine, smart card antenna implant:

1. Intelligent search frequency, lengthening the life of buried line 2-3 times.

2. Do not dip tin before welding, reduce the process and cost.

3. Matching powerful, buried head and ultrasonic generator can be interchangeable.

4. Multi-point power control, high-speed embedding, consistency is good.

5. Solving the problem of equipment heating when embedded, can work for a long time.

6. Standardized design can directly replace imported products, environmental protection and safety.


The equipment is used for the coil embedded in a smart card.

There are 3 different technique to produce PVC Card Inlay, pre-winding, ultrasonic and Flip.

Among them, the cards made by Flip will have very flat surface, and very thinner thickness; for ultrasonic, it has the best working performance no matter for the reading distance, or the card's surface; also, the cost of pre-winding is more cheaper than ultrasonice and Flip.
