High Power Ultrasonic Welding Equipment 20kHz Digital Type Used in Blank Mask Making Machine

  • China
  • Altrasonic
  • HS-W20
  • Shanghai or Ningbo
  • Silver
  • 1
  • T/T, PayPal, West Union

  • Contact Now
Product Details

High Power Ultrasonic Welding Equipment 20kHz Digital Type Used in Blank Mask Making Machine



Application:


Ultrasonic  welding is also utilized in the medical industry, primarily because it doesn’t introduce contaminants. Items such as anesthesia filters, blood filters, IV catheters, dialysis tubes and face masks can be made using ultrasonic plastic welding. Another important application in the medical field is the construction of such textile wear as hospital gowns, surgery garments, and transdermal patches, just to name a few. These items can be sewn and sealed using ultrasonic welding to avoid and reduce the risk of infection.



Description:


The principle of ultrasonic mask machine welding mainly uses ultrasonic technology to transmit ultrasonic energy to the welding zone through the upper welding piece. Due to the large acoustic resistance at the welding interface, which is the interface between the two weldings, local high temperatures will occur. In addition, due to the poor thermal conductivity of plastics, nylon, chemical fibers, non-woven fabrics, multi-layered fabrics, and gold fabrics, they cannot be distributed in time and gather in the welding zone, causing the two contact surfaces to melt rapidly. After applying a certain pressure, Fusion into one. When the ultrasonic wave stops functioning, the pressure is allowed to continue, and the pressure is maintained for a while, so that it solidifies and forms, so that a strong molecular chain is formed to achieve the purpose of welding, and the welding strength can be close to the strength of the raw material body.



Specification:


Frequency: 20kHz

Max Power: 2000Watt

Voltage: 110V / 220V, 50-60Hz

Working Temperature:5°C - 50°C

Generator:Digital

Steel horn: 110*20mm



Advantage:


1. Short welding times (in the order of tenth of seconds)

2. Aesthetic perfection

3. Waterproof welding stable for a long time

4. Labor savings

5. Energy-efficient

6. Flexibility

7. Possibility of welding even in the presence of foreign bodies

8. Excellent mechanical seal

9. Eliminating the use of solvents and adhesives.
