Ultrasonic Sewing For Fabric Edge Trimming

Product Details

Ultrasonic Sewing For Fabric Edge Trimming



Minimum Order Quantity:

1 Set

Price:

Ask for quote

Packaging Details:

Wood case

Delivery Time:

In 7 Working Days

Payment Terms:

T/T, WESTERN UNION

Supply Ability:

100 Sets/Month



Quick Detail:



Fast weld
High strength
Good tightness
Simplicity of operator
Low energy consumption





Description:



The work method of Seamless sewing part is completely imitating traditional sewing machine. The biggest characteristic is the ultrasonic transmit horn work direction is same with the sewed cloth. Which will make the sewed point of the cloth are even, flat and fastness. Through suitable design, it can reach perfect sewing effectiveness.





Applications:



Usually used in clothing industry is the ultrasonic lace machine, which is mainly used in cutting and welding cloth. Owing to its transmit horn is a plane, so it only can turn its own geometric center and cant turn the same direction with the cloth. Which make the sewed point of the cloth is unevenness. The transmit horn of Seamless sewing part is a circumference horn, and can turn around . For the cloth, it is jointing with the cloth and working at the same time. The ultrasonic seamless sewing part advance ultrasonic lace machine and its market prospects are very bright.





Specifications:

Model

W-35R

Frequency

35 KHz

Power

600 W

Rotary Welding Horns Width

12 mm

Power Adjust Method

File or Continuous

The Horns Surface Hardness

More than HRC56

Real-time Display

Working Frequency and Working Current

Synchronizing Wheel Specifications

46XL Trapezoidal Tooth,Width16mm

Synchronizing Belt Matched

The Length is not more than730mm,the Width 12mm

Allowable Rotation Speed

100 r/min.

Install Bolt

M8, 4 pcs
