Digital High Frequency Ultrasonic Generator Spot Welding for PVC Between Thin Cardboard

  • China
  • Altrasonic
  • Blue
  • 1

  • Contact Now
Product Details

Digital High Frequency Ultrasonic Generator Spot Welding for PVC Between Thin Cardboard



Minimum Order Quantity:

1 Set

Price:

Ask for quote

Packaging Details:

Wood case

Delivery Time:

In 7 Working Days

Payment Terms:

T/T, WESTERN UNION

Supply Ability:

200 Sets/Month



Cheap
Simple structure
Easy to repair


Description:

The ultrasonic generator, also called ultrasonic driving power supply, electronic box, control box, is an important part of high power ultrasonic system. Main function is to generate high power and high frequency alternating current, drive the ultrasonic transducer.


Applications:

Ultrasonic generator main function is to generate high power and high frequency alternating current, drive the ultrasonic transducer.
Ultrasonic generator is applied to all kinds of ultrasonic equipment, mainly with ultrasonic welding, ultrasonic cutting, ultrasonic chemical equipment and ultrasonic welding equipment such as non-woven fabric.







Specifications:


Model

ZJS-500N

Frequency

15 KHz – 60 KHz

Size

300*450*170 mm

Weight

12 KG

Output Power

100 – 3000 W

Voltage

220 V    50 Hz

Temperature

≤300℃

Moisture

≤85%RH



Competitive Advantage:

★ The use of high-quality electronic components assembly.
★ Advanced and reliable protection circuit makes the reliability is greatly improved.
★ FM and frequency automatic compensation, frequency of the digital display.
★ Frequency deviation, working current two meter indication and protection function.
★ According to the customer request interface plug.
★ Has the advantages of simple structure, easy to repair, cheap.


Comparison:




Analog generator

Digital generator

Circuit

Analog circuit, discrete components

Digital circuit, the chip control

Automatic search

×

Automatic frequency tracking

×

Frequency adjustment range

±0.15 KHz

±0.5 KHz

Power regulation

×

24 hours of continuous work

×

Non resonant condition

×

LCD

×

Add the PLC protocol

×

Automatic circuit protection

Bad, easy to cause the damage of components

Good

Repair method

Professional repair

Module replacement





Previous70KHZ Digital Ultrasonic Generator For Samrt Card Bank Card ID Card Embedding

Next15K 2000W High Power Generator For Plastic Welding
