20KHz Ultrasonic Slitting And Cutting With Food Industry Approved Titanium Blade Non Sticking

20KHz Ultrasonic Slitting And Cutting With Food Industry Approved Titanium Blade Non Sticking

20KHz Ultrasonic Slitting And Cutting With Food Industry Approved Titanium Blade

  • Item No.:

    HS-C20
  • Payment:

    T/T, Paypal, Western Union
  • Price:

    $4599/PC
  • Product origin:

    China
  • Color:

    Silver and Blue
  • Shipping port:

    Ningbo or Shanghai
  • Product Details


20KHz Ultrasonic Slitting And Cutting With Food Industry Approved Titanium Blade Non Sticking



Parameters:



 Product Name  Ultrasonic food cutter
 Brand Name  Altrasonic
 Place of Origin  China
 Frequency  20kHz
 Output power  1000W
 Generator  Digital
 Blade length  125/255/305mm/ Customize
 Blade material  Titanium alloy/ Stainless
 Voltage  220V/110V
 Temperature   0℃-40℃
 Weight  15kg-18kg
 Application  Food Industry
 Power Controller  Stepping or continuous
 Certification  CE
 Packing  Foam+Carton+Wooden box





Description:



Whether in large industrial bakeries, in confectionery manufacture or cheese-making – our ultrasonic cutting technology is versatile in application.

Bakery products containing cream or sugary layers, as well as other dough or fat-containing foods, can be cut or trimmed in a controlled way by ultrasound to produce a quality that is visually appealing. The cutting geometries of the tools for longitudinal or cross cuts are individually tailored to product requirements.

As a result of ultrasonic vibrations, only slight product residues remain adhered to the sonotrode, so that to a certain extent, it demonstrates a self-cleaning action.

Because of the ultrasonic vibrations, cutting sonotrodes work with a lower initial pressure than conventional cutters. At the same time, sonotrode wear is less and the cutting quality is considerably better. In addition, the use of ultrasonic cutting systems has a positive effect on the maintenance and down times of the equipment.



Advantage:


1. Pleasing cut and form stability

2. Product-specific cutting geometries

3. Cutting sonotrodes with little product adhesion and self-cleaning action

4. Reduction in maintenance and down times

5. Products cut almost irrespective of consistency
